Car Stackers

multibase U3

Simply let your system disappear underground. The premium underfloor systems from KLAUS Multiparking no longer move upwards but move one, two or three levels downward. The upper platform when lowered is flush with the ground. Above ground, you gain a car-free area, which you can now design according to your own ideas – for an increased value for your real estate. The type MultiBase U3 is traversable and can thus be used in courtyards, front gardens and green areas. They combine highest comfort with optimum use of space. The modern systems set new technological standards and offer space for up to six cars. This way, parking space for cars can be realized where no space was available so far, even in inner courtyards or confined access areas.

A true improvement in everyday quality of life.

Specification

• Single platforms (EB) U3 for 3 vehicles or double-platforms (DB) for 6 vehicles
• Pit depth of standard type: 605 / 610 cm
• Vehicle measurement: Heights from 165 cm, lengths from 500 to 520 cm
• Usable platform width for standard type: 230/460 cm, optionally up to max. 270/540 cm
• Standard design: 2.000 kg per parking space, optional max. 2.600 kg EB / DB
• Horizontal access to all parking levels
• Flush-mounted and traversable, controlled rainwater drainage
• Freely configurable surface area: cassette-construction lid, which can be adapted to surroundings based on customer request (e.g. stone lining, turf)
• Platform surface: StandardGrip, optional AluLongLife or EasyWalk
• Independent parking
